Additional Features

6.1

Buttons

The conga-HPC/EVAL-Server features two push buttons—power and reset buttons.
6.1.1

Power

When using an ATX power supply, the COM-HPC
6.1.2

Reset

The COM-HPC ® module and all connected components will perform a hard reset when this button is pressed. The reset button SW6 is
connected to the COM-HPC
6.2

Ground Test Points

The conga-HPC/EVAL-Server provides four test points (M1-M4). These test points make it easier to connect oscilloscope probes or multimeter
to ground during measurements on the COM-HPC
Copyright © 2022 congatec AG
® module starts after the power-on button SW5 is pressed.
SW5
® module's RSTBTN# signal.
module.
®
M1-M4
SW6
HEVAm100 52/54
