A28 ETH6_TX- B28 GND
A29 GND B29 ETH7_RX+
A30 GND B30 ETH7_RX-
A31 ETH7_TX+ B31 GND
A32 ETH7_TX- B32 GND
A33 GND B33 NC
A34 GND B34 NC
A35 GND B35 GND
A36 GND B36 GND
A37 GND B37 GND
A38 +V12S B38 +V12S
A39 +V12S B39 +V12S
A40 +V12S B40 +V12S
Connector Type
X42: congatec Ethernet Mezzanine Card
4.3

DisplayPort

The conga-HPC/EVAL-Server provides a DisplayPort connector (X33) via the BMC —providing display capability without an additional cost for
DP add-on-card. The BMC controls the graphic output via PCIe_BMC_TX and PCIe_BMC_RX pins.
The DisplayPort supports:
• VESA DisplayPort specification version 1.1a
• data rate of 2.7 or 1.62 Gbps per lane
• AUX channel transceiver
• video compression of high graphics display resolution modes up to 1920x1200x32bpp
• maximum display resolution of 1920x1200 at 60 Hz and 32 bpp
Note
DisplayPort++ is not supported.
Connector Type
X33: Standard DP plug
Copyright © 2022 congatec AG
C28 NC D28 ETH4-7_MDIO_DAT
C29 GND D29 ETH4-7_MDIO_CLK
C30 GND D30 ETH7_SDP
C31 NC D31 ETH4-7_PHY_INT#
C32 NC D32 ETH4-7_PHY_RST#
C33 NC D33 GND
C34 NC D34 ETH4-7_PRSNT#
C35 GND D35 GND
C36 GND D36 GND
C37 GND D37 GND
C38 +V12S D38 +V12S
C39 +V12S D39 +V12S
C40 +V12S D40 +V12S
HEVAm100
X33
