Section 2: Pump Setup and Programming

Attaching a Cassette

Obtain a new, filled Medication Cassette
Administration Set attached to a non-vented, flexible IV bag.
WARNING: For detailed instructions and warnings pertaining to
the Medication Cassette
please refer to the instructions for use supplied with the product for
preparing the product for use.
After attaching the cassette, proceed to the Reservoir Volume screen
to reset the value for the volume, and then prime the tubing.
WARNING: Frozen medication must be thawed at room tempera-
ture only. Do not heat the Medication Cassette
microwave oven as this may damage the medication, the Medica-
™
tion Cassette Reservoir, or cause leakage.
To attach the cassette to the pump
1. Clamp the tubing.
2. Insert the cassette hooks into the hinge pins on the pump.
3. Place the pump upright on a firm, flat surface. Press down
so the cassette fits tightly against the pump.
32
™
™
Reservoir or CADD
1999-08-17 D. Zurn
«Lgc Attach Cass Coin»
Reservoir, or CADD
®
Administration Set,
™ Reservoir in a
®
