Section 1: General Description
Power Jack
You may plug an AC Adapter into the Power jack as an alternate
source of power. The indicator light on the front of the pump will
illuminate when the AC Adapter is in use.
Accessory Jack
This jack is used for accessory cables. See the Instructions for Use
supplied with those accessories.
Air Detector
The Air Detector is on the pump in the area shown in the diagram.
If air is detected in the part of the tubing that passes through the Air
Detector, an alarm sounds and delivery stops. (See Section 5 for Air
Detector specifications.) If an Air Detector is not required, it may be
turned off. (See Section 4, Biomed Functions.)
WARNING: When the Air Detector is turned off, the pump will not
detect air in the fluid path. Periodically inspect the fluid path and
remove any air to prevent air embolism. Air embolism could result
in death or serious injury to the patient.
Cassette
The cassette is the portion of the Medication Cassette
®
or CADD
Administration Set that attaches to the bottom of the
pump. The following single-use products are compatible with the
CADD-Legacy
™
pump:
• Medication Cassette
the CADD
• CADD
®
Administration Set with integral Anti-Siphon Valve
• CADD
®
Administration Set with Add On Anti-Siphon Valve
WARNING: You must use a CADD
Anti-Siphon Valve or a CADD
either an integral or an Add On Anti-Siphon Valve to
6
™
Reservoir (50 or 100 ml), used with
®
Extension Set with Anti-Siphon Valve
™
®
Extension Set with
®
Administration Set with
Reservoir
