Section 5: Reference
ful power up is indicated with six audible beeps and the
"STOP" screen displayed. Continue with the lock check.
Lock Check
• Attach a 50 or 100 ml Medication Cassette
CADD
®
Administration Set to the pump. The line on the
lock should be aligned with the arrow on the side of the
pump.
Cassette Sensor Check
• Unlock the cassette by inserting a coin into the lock and
turning clockwise.
• The pump will sound a continuous two-tone alarm and the
display should show "No Disposable, Clamp Tubing."
• Press
to turn the pump off.
The following three checks (LCD, Motor and Gear Train and Reser-
voir Volume Empty Alarm Check) should be performed in the se-
quence shown.
LCD Check
• With the pump turned off, press
that the pump displays will consist of 32 blocks of charac-
ters. Examine the LCD to verify that there are no missing
dark in the character blocks.
Motor and Gear Train Check
• Program the Reservoir Volume to 2.0 ml.
• Attach a 50 or 100 ml Medication Cassette
CADD
®
Administration Set to the pump. Lock the cassette.
• Press and hold
70
or
to silence the alarm. Press and hold
until three series of dashes appear.
Reservoir or
Å
. The second screen
Reservoir or
Å
