3.5.2 Attaching the Cassette

Obtain a new, filled Medication Cassette
Set attached to a nonvented fluid container. Refer to the instructions for use
supplied with the product for preparing the product for use.
Ensure that the fluid path tubing is closed with the clamp.
•
Insert the cassette hooks into the hinge pins on the pump and place the pump
•
upright on a firm, flat surface.
®
Press down on the pump so the cas-
•
sette fits tightly against the bottom of
the pump. Lock the cassette in place
by inserting a coin into the slot in the
locking button, pushing the button
in; and then turn the coin one-quarter
turn counterclockwise until a definite
stop is felt.
Gently twist and pull on the cassette
•
to make sure it is firmly attached.
WARNING:
It is essential that you attach the cassette properly. When you attach the cassette
properly, the coin slot of the locking button aligns w ith the arrow on the side
of the pump case. If you do not attach the cassette properly, an uncontrolled flow
of medication from the fluid container or a reflux of blood may result, w hich
could result in death or serious injury to the patient.
To protect against unregulated gravity infusion that can result from an
improperly attached cassette, a CADD
®
or a CADD Administration Set w ith either an integral or Add O n Anti-Siphon
Valve must be used.
Reservoir, or CADD
™
®
10/06/95 D. Zurn
Extension Set w ith Anti-Siphon Valve
®
Administration
®
LOCKED
LOCKED
