7. The pump should alarm when the syringe is between 0.5
and 0.1 ml.
Occlusion Pressure Range Test II
Description
An adjustable metered pressure source is connected to the Medication
Cassette ™ Reservoir tubing. The pressure is slowly increased until the
high pressure alarm sounds.
Equipment needed
Pressure gauge, 40 ± 1 psi [2.76 ± 0.07 bar]
Pressure vessel, partially filled with water
Pressure regulator, 40 psi [2.76 bar]
50 or 100 ml Medication Cassette
Procedure
1. Insert two AA batteries and wait for the pump to power up.
2. Attach a Medication Cassette
NOTE: The pressure from the source must be zero when the
cassette is attached.
3. Assemble the apparatus as shown.
1999-01-23 D. Zurn
«Lgc Occlusion NoText»
™
Regulator Pressure Gauge
Section 5: Reference
™ Reservoir containing water
Reservoir to the pump.
