USB Deviceserver User Manual macOS
4. Optional: If you want to save the monitoring logs for a single day to subfolders, enable the Create individual
directories for days option.
Important:
The FIFO principle (first-in, first-out) is applied after one year. For example, 1 Janu-
ary of last year will overwritten with files from 1 January of the current year.
5. In the WebDAV – Backup area, enable the Daily backup at option.
6. From the list, select the hour at which the backup will be transferred.
7. To confirm, click Save.
 The settings will be saved.
Immediately Exporting Monitoring Logs via WebDAV
 Your network has a WebDAV server.
 WebDAV is configured on the UTN server  49.
 Monitoring is enabled  59.
1. Start the utnserver Control Center.
2. Select DEVICE – Monitoring.
3. In the WebDAV – Server area, enter the directory on the WebDAV server where the monitoring logs are to be
stored in the Directory box.
4. Optional: If you want to save the monitoring logs for a single day to subfolders, enable the Create individual
directories for days option.
Important:
The FIFO principle (first-in, first-out) is applied after one year. For example,
January 01 of last year is overwritten with the files of the current January 01.
5. Click the Export manually now button.
 The monitoring logs are stored on the WebDAV server.
Continuously Exporting Monitoring Logs via Email
 SMTP is configured on the UTN server  46.
 Monitoring is enabled  59.
1. Start the utnserver Control Center.
2. Select DEVICE – Monitoring.
3. In the Email – Recipient area, enter the email address of the recipient where the monitoring logs will be sent
in the Email Address box.
4. In the Email – Recipient area, enter the content of the email subject line for monitoring log emails in the
Email Subject box.
(You can specify the content of the email subject line with a–z, A–Z, 0–9 and using variables:
%P = product type
%I = IP address
5. In the Email – Backup area, enable the Continuous Backup option.
6. To confirm, click Save.
 The settings will be saved.
%p = model
%M = MAC address
%N = default name
%E = event
61
Device Settings
%H = host name
%D = date %t = time)
