USB Deviceserver User Manual macOS
Table 8.3-17: Parameter list – TCP port access
Parameters
protection
[Port access control]
protection_level
[Security level]
ip_filter_on_1
~
ip_filter_on_
(max. Ports)
[IP address]
ip_filter_1
~
ip_filter_
(max. Ports)
[IP address]
hw_filter_on_1
~
hw_filter_on_8
[MAC address]
hw_filter_1
~
hw_filter_8
[MAC address]
protection_test
[Test mode]
Value Default
on/off off
protec_utn protec_utn
protec_tcp
protec_all
on/off off
valid IP address [blank]
on/off off
Valid MAC address 00:00:00:00:0
0:00
on/off on
Description
Enables/disables the blocking of selected ports
and thus connections to the UTN server.
Specifies the port types to be blocked.
protec_utn= UTN access (UTN ports)
protec_tcp= TCP access (TCP ports: HTTP/
HTTPS, UTN)
protec_all= all ports (IP ports)
Enables/disables an exception from port block-
ing.
Defines networks elements that are excluded
from port blocking by their IP address.
The prefix notation "<IP address>/<prefix
length>" can be used to freely define
IPv4 and IPv6 subnets.
Enables/disables an exception from port block-
ing.
Defines elements that are excluded from port
blocking by their MAC address (MAC address).
Important:
MAC addresses are not delivered
through routers!
Enables/disables the test mode.
WARNING
The test mode is active by default
so that you can test your settings
without locking yourself out. Your
settings will be active until the UTN
is restarted, afterwards access is no
longer restricted.
After you have successfully tested
your settings, you have to deacti-
vate the test mode so that access
control is permanent.
118
Appendix
