USB Deviceserver User Manual macOS
Define a IP Client VLAN
1. Start the utnserver Control Center.
2. Select NETWORK – IP VLAN.
3. Configure the IP VLAN parameters; table 4.3-2 44.
4. To confirm, click Save.
 The settings will be saved.
Table 4.3-2: IP client VLAN parameters
Parameters
VLAN
IP Address
Prefix length
Router
VLAN ID
Use Auto-fill to automatically fill VLAN, IP address and Subnetmask with the val-
ues from line 1. VLAN ID will automatically be counted up by '1'.
Allocating a IP Client VLAN to a USB Port
1. Start the utnserver Control Center.
2. Select SECURITY – USB.
3. Select the appropriate VLAN assignment from the VLAN drop-down list.
4. To confirm, click Save.
 The settings will be saved.
Description
Enables/disables the forwarding of IP client VLAN data.
IP address of the UTN server within the IP client VLAN.
The IP address and the prefix length defines the network mask of the UTN
server.
Router address of the IP client VLAN.
ID for the identification of the IP client VLAN (0–4096).
44
Network Settings
