USB Deviceserver User Manual macOS
Table 8.3-3: Parameter list – IP-VLAN
Parameters
iplan_mgmt
[IP management
VLAN]
ipvlan_mgmt_idx
[VLAN-ID]
ipvlan_mgmt_any
[Access from any
VLAN]
ipvlan_mgmt_untag
[Access via LAN
(untagged)]
ipvlan_on_1
~
ipvlan_on_20
[VLAN]
ipvlan_addr_1
~
ipvlan_addr_20
[IP address]
ipvlan_mask_1
~
ipvlan_mask_20
[Prefix length]
ipvlan_router_1
~
ipvlan_router_20
[Router]
ipvlan_id_1
~
ipvlan_id_20
[VLAN-ID]
utn_2vlan_1
~
utn_2vlan_20
[Allocate VLAN]
Value Default
on/off off
0-4096 0
[1–4 characters; 0–
9]
on/off off
on/off on
on/off off
valid IP address 192.168.0.0
valid IP address 255.255.255.
0
valid IP address 0.0.0.0
0-4096 0
[1–4 characters; 0–
9]
0-9 0
[1 character; 0–9]
Description
Enables/disables the forwarding of IP manage-
ment VLAN data.
If this option is enabled, SNMP is only available
in the IP management VLAN.
ID for the identification of the IP management
VLAN.
Enables/disables the administrative access
(web) to the UTN server via IPv4 client VLANs.
If this option is enabled, the UTN server can be
administrated via all VLANs.
Enables/disables the administrative access to
the UTN server via IP packets without tag.
If this option is disabled, the UTN server can
only be administrated via VLANs.
Enables/disables the forwarding of IP client
VLAN data.
IP address of the UTN server within the IP client
VLAN.
Subnet mask of the UTN server within the IP cli-
ent VLAN.
IP router address in the IP management VLAN.
With a router, you can address IP addresses from
other networks.
ID for the identification of the IP client VLAN.
Allocates a VLAN to the USB port.
0 = any
1 = VLAN 1
2 = VLAN 2
usw.
9 = none
102
Appendix
