Set Label Width - Intermec EasyCoder C4 Programmer's Manual

q – Set Label Width
Description
Syntax
Parameters
Remarks
Example
Intermec EasyCoder C4 – Programmer's Guide Ed. 3
This command is used to set the label width when using less than full width labels.
qp
1
p Width of label measured in dots. Default: 832.
1
The q command will cause the image buffer (see
to match the label width, that is width is traded off for increased length within
the same memory size.
The q command will also automatically set the margins according to the
following rule:
(No. of dots on printhead - label width in dots)/2 (center-aligned)
There are 8 dots per mm and 203.2 dots per inch.
Important!
If an R command (Reference Point) is sent after a q command, the image buffer
will be automatically reformatted to match the width of the printhead and the
margins will be reset accordingly.
q416
Chapter 7 Commands
M command) to be formatted
:Sets label width to 416 dots
79
