B – Standard Bar Codes
Description
Syntax
Parameters
Intermec EasyCoder C4 – Programmer's Guide Ed. 3
This command is used to print standard bar codes.
Bp ,p ,p ,p ,p
1 2 3 4 5
p Horizontal start position (X) in dots.
1
p Vertical start position (Y) in dots.
2
p 0 No rotation.
3
1 90 degrees rotation clockwise.
2 180 degrees rotation clockwise.
3 270 degrees rotation clockwise.
p Barcode select. See table below.
4
p Narrow bar width in dots. See table below.
5
Bar Code Type
Code 39 std. or extended
Code 39 with check digit
Code 93
Code 128 UCC case code
Code 128 A, B, C
Codabar
EAN8
EAN8 2 digit add-on
EAN8 5 digit add-on
EAN13
EAN 13 2 digit add-on
EAN13 5 digit add-on
Interleaved 2 of 5
Interleaved 2 of 5 with check digit
Interleaved 2 of 5 with human readable check digit
Postnet 5, 6. 8 & 11 digit
UCC/EAN 128
UPC A
UPC A 2 digit add-on
UPC A 5 digit add-on
UPC E
UPC E 2 digit add-on
UPC E 5 digit add-on
UPC Interleaved 2 of 5
p Wide bar width in dots (2 -30).
6
p Barcode height in dots.
7
p B Human readables ON.
8
N Human readables OFF.
"DATA" Represents a fi xed data fi eld.
,p ,p ,p ,"DATA"
6 7 8
Chapter 7 Commands
"p " "p "
4 5
3 1-10
3C 1-10
9 1-10
0 1-10
1 1-10
K 1-10
E80 2-4
E82 2-4
E85 2-4
E30 2-4
E32 2-4
E35 2-4
2 1-10
2C 1-10
2D 1-10
P n.a.
1E 1-10
UA0 2-4
UA2 2-4
UA5 2-4
UE0 2-4
UE2 2-4
UE5 2-4
2U 1-10
29
