b – PDF417, cont.
Remarks
Example
Intermec EasyCoder C4 – Programmer's Guide Ed. 3
If parameter www (max. print width) gives less space than required by the
sum of parameters x- (module width) and l- (max. column count), error
condition 50 will occur.
Likewise, if parameter hhh (max. print height) gives less space than required
by the sum of parameters y- (set bar height) and r- (max. row count), error
condition 50 will also occur.
N
b40,40,P,400,300,p40,340,20,f1,x3,y10,r60,l5,
"ABCDEFGHIJK1234567890abcdefghijk"
P1
Note that the last parameter in the b command above (l5) is lowercase L + 5, not 15!
