Gg Print Graphics - Intermec EasyCoder C4 Programmer's Manual

GG – Print Graphics
Description
Syntax
Parameters
Remarks
Example
Intermec EasyCoder C4 – Programmer's Guide Ed. 3
This command is used to print a graphic that has been previously stored in
memory.
GGp ,p ,"name"
1 2
p Horizontal start position (X) in dots.
1
p Vertical start position (Y) in dots.
2
"name" This is the name used when the graphic was stored. The name may be from
1 to 8 characters. The printer is case sensitive,that is the use of upper and
lower case letters must match the original name.
A graphic can only be printed in same direction and size as when it was saved.
There are no means of magnifi cation or rotation of an individual graphic. However,
the entire print image including all text, bar codes, graphics, lines, and boxes can be
rotated 180° using the
GG50,50,"LOGO"
Z command.
Chapter 7 Commands
:Prints the graphic "LOGO"
52
