US – Enable Error Reporting
Description
Syntax
Remarks
Example
Intermec EasyCoder C4 – Programmer's Guide Ed. 3
This command is used to enable the printer's status reporting feature.
US
Serial Port:
If an error occurs while using the serial port, the printer will send a NAK (ASCII 21
dec.), followed by the error number, back to the computer. If no error occur, the printer
will echo ACK (ASCII 06 dec.) after each
If out-of-media or out-of-ribbon occurs, the printer will send, through the serial port, a
"-07" and "Pnnn" where nnn is the number of forms remaining to print.
Parallel Port:
While using the parallel port, the printer will print the error number and the
control lamp will go orange (error).
The default setting is off (also see UN).
Error Messages
Message Meaning
ERR01 Syntax Error
ERR02 Object exceeds image buffer border
ERR03 Data length error (for example EAN 13 is 12 or 13 bytes only)
ERR04 Insuffi cient memory to store forms or graphics
ERR05 Memory confi guration error
ERR06 RS-232 error
ERR07 Out of media and/or ribbon
ERR08 Form or PCX name duplicate
ERR09 Form or PCX not found
ERR16 No form was retrieved before "? " was entered.
ERR50 Does not fi t in area specifi ed
ERR51 Data length too long
HINT!
Tap the Feed key three times to resume printing after an error.
US
Chapter 7 Commands
P (print) command.
:Enables error reporting
90
