Example, cont.
Command
X0,0,4,752,584
LO0,144,752,4
LO440,232,4,160
Command
A40,400,1,1,1,1,N,"Made in Sweden"
Command
A24,160,0,5,1,1,R,V00
Command
A24,250,0,4,1,1,N,"MODEL: "V01
A472,312,0,4,1,1,N,"Checked by: "V02
Intermec EasyCoder C4 – Programmer's Guide Ed. 3
Draw a Box and two Lines
Start to draw the surrounding box using the X command and then
draw the two lines using the LO command.
Explanation
Draw a box
Draw a black line
Draw a black line
Place a Text Line with Fixed Data
Enter a 90° rotated text line containing the fi xed data "Made in
Sweden" in text size 1. The quotation marks enclosing the fi xed
data will not be printed. The text size (1) is the smallest resident
font in the printer.
Explanation
90 degree. text line, fi xed data
Place a Variable Text
The next line is a text line, using text size 5 in reverse and prints the
variable V00. The data printed in this fi eld must be sent to the printer
at the time of form retrieval.
Explanation
Write a text line, 1:st variable
Place a Combination of Fixed Data and a Variable
The following two command lines consist of a combination of fi xed
data enclosed in quotation marks and variable data.
Explanation
Text line, fi xed data + 2:nd variable
Text line, fi xed data + 3:rd variable
Chapter 5 Editing in Form Edit Mode
