3

INSTALLATION AND CONNECTIONS

I Unpacking

After unpacking, immediately report any damage to the
delivering carrier or dealer. Keep the shipping cartons.
For a description and a diagram of accessory equip-
ment included with the IC-910H, see 'Supplied acces-
sories' on p. 1 of this manual.

I Grounding

To prevent electrical shock, television interference
(TVI), broadcast interference (BCI) and other prob-
lems, ground the transceiver through the GROUND
terminal on the rear panel.
For best results, connect a heavy gauge wire or strap
to a long earth-sunk copper rod. Make the distance be-
tween the [GND] terminal and ground as short as pos-
sible.
R WARNING: NEVER
terminal to a gas or electric pipe, since the connec-
tion could cause an explosion or electric shock.
PL-259 CONNECTOR INSTALLATION EXAMPLE
q
Coupling ring
10 mm (soft solder)
w
e
r
14
connect the [GND]
30 mm
Slide the coupling ring
down. Strip
jacket and soft solder.
10 mm
Soft
Strip the cable as shown at
solder
left. Soft solder the center
conductor.
1–2 mm
solder solder
Slide the connector body
on and solder it.
Screw the coupling ring
onto the connector body.
From The N3UJJ.COM Document Library From The N3UJJ.COM Document Library

I Selecting a location

Select a location for the transceiver that allows ade-
quate air circulation, free from extreme heat, cold, or
vibrations, and away from TV sets, TV antenna ele-
ments, radios and other electro-magnetic sources.

I Antenna connection

For radio communications, the antenna is of critical im-
portance, along with output power and sensitivity. Se-
lect antenna(s), such as a well-matched 50 Ω antenna,
and feedline. 1.5:1 or better of Voltage Standing Wave
Ratio (VSWR) is recommended for your desired band.
Of course, the transmission line should be a coaxial
cable.
CAUTION:
by using a lightning arrestor.
TYPE-N CONNECTOR INSTALLATION EXAMPLE
Nut Rubber gasket
q
the cable
w
Clamp
e
r
Be sure the center conductor is
the same height as the plug body.
30 mm ≈
The base of the trans-
ceiver
justable stand for desk-
top use. Set the stand
to depending on your
operating conditions.
Protect your transceiver from lightning
15 mm Slide
gasket and clamp over the
coaxial cable, then cut the
end of the cable evenly.
Washer
Center
conductor
Strip the cable and fold the
braid back over the clamp.
3 mm
6 mm
Solder hole
Soft solder the center
conductor.
center conductor pin and
solder it.
No space
Carefully slide the plug
body into place aligning the
center conductor pin on the
cable. Tighten the nut onto
the plug body.
in 10 mm ≈ in 1–2 mm ≈
9 3
⁄ ⁄
8 8
has an ad-
the nut, rubber
Install the
1
⁄ in
16
