SECTION 4 Diagnostic Tools
2.11.4
2.11.5
2.11.6
2.11.7
4–30

Printing (Head 1-4)

Access Level: Read–3
When Activate Timing is On, the Printing parameter reports the time
spent by the FPGA actually printing a single printhead's image from
the point the FPGA is told to begin until the FPGA interrupts to say it
is done. This does not include any registration or product sensor
debounce time. It does not include the time to save the printing bar
code data in the image.

Time Fields

Access Level: Read–3
When Activate Timing is On, the Time Fields parameter reports the
time it takes to re-render all the time-based fields (BBE and Time/
Date) in the Render buffers. The time includes the time to re-render
all the slant images which were affected if Slant mode is enabled.

Incremental Fields

Access Level: Read–3
When Activate Timing is On, the Incremental Fields parameter
reports the time it takes to re-render all the incremental fields in the
Render buffers. The time includes the time to update all the slant
images which were affected if Slant mode is enabled.

Remote Select

Access Level: Read–3
When Activate Timing is On, the Remote Select parameter reports
the time it takes to process a remote Product Select message
(ASCII Comms or Host port).
For the Host port, this includes the time to reply with a Status
response message.
The time does not include the time to receive any label files from the
Host if in the Host Database mode.
The time does not include the time to render and copy the label.
0855855eng 6/08
