SECTION 2 Basic Operation
3.2.2
3.2.3
2–8
Function Keys
The F1, F2, F3, and F4 keys are function keys. Pressing one of
these keys selects the button described above it on the display.
Depending on the menu, the available functions will vary. Function
keys often open new menus.
Job: Chocolate
Status
Machine: Ready
State: Printing
Ink: OK
Counts:
Batch : 999
Total : 53796
- Press ENTER to preview image -
Job Reg.
Select + / -
ENTER and EXIT Keys
The ENTER key (1) is used to open the selected menu. Changes
that were made to the current menu will be saved when the ENTER
key is pressed.
The EXIT key (2) is used to return to the previous menu.
4
2
15 Feb 2008 15:17:49
PH1: On
PH2: On
Shutdown Main
Menu
3
1
5
0855855eng 6/08
