Specifications

0855855eng 4/09
0855855eng 6/08
SECTION 1 General Information
Weight:
Dimensions:
Noise Emission:
Electrical Standards:
Voltage Options:
Environmental:
Print Area:
Print Speed:
Warm-up Time:
Interface:
Print Resolution:
Bar Code Type:
Print station (not including umbilical lines)
Model 5200: Approx. 63kg (140 lb)
Model 5400: Approx. 77kg (170 lb)
Printhead: Approx. 2.1kg (4.6 lb)
See Dimensional Drawing (Paragraph 3.0)
Does not exceed 75 dB(A)
CE marked
ETL listed, conforms to ANSI/UL 60950 and
Canada/CSA 60950
Model 5200: 1450W maximum,
115/200/208/230V, 50–60Hz, single phase
Model 5400: 2530W maximum,
200/208/230V, 50–60Hz, single phase
Temperature range
Standard 5200/5400: 0°–40°C (32°–104°F)
Stainless 5200/5400: 0°–25°C (32°–77°F)
Relative humidity
<90%, non-condensing
IP Protection
Enclosure: IP45 (with doors latched)
Printhead: Not rated
Carton Sensor: IP65
Encoder: IP65
65mm x 1200mm (2.56" x 47")
55m/min. (180 ft./min.) at Density 2
(recommended)
60 minutes
RS232 serial port
RS422 serial port
RS485 serial port
Ethernet 10T/100T
100 DPI Vertical
150 DPI Horizontal
Code 39, EAN 128, Interleaved 2 of 5
UPC-A, EAN 13, 2D Bar Code
