SECTION 4 Diagnostic Tools
2.6.4
2.6.5
2.6.6
2.6.7
2.6.8
2.6.9
4–20

Enclosure Temperature

Access Level: Read–3
The Enclosure Temperature parameter displays the ambient
temperature inside the enclosure at the circuit boards. Machine
problems may occur if this temperature exceeds 60° C.

Product Sensor 1 and 2 (PS1 and PS2)

Parameter Options: Active, Inactive
Access Level: Read–3
The Product Sensor parameter displays the status of each product
sensor and will only be displayed if a printhead is configured for that
particular sensor.

Remote Purge (PS4)

Parameter Options: Active, Inactive
Access Level: Read–3
The Remote Purge parameter displays the status of the remote
purge input. The remote purge input uses the product sensor 4 input
for its connection. The Remote Purge feature must be enabled on
the Machine Setup / Print Station Settings menu for this diagnostic
to function. When active, all printheads that are ready will perform a
purge.

Encoder 1 and 2

Access Level: Read–3
This Encoder parameter displays the line speed of each encoder
and will only be displayed if a printhead is configured for that
particular encoder.

Fault Relay

Parameter Options: On, Off
Access Level: Read–3; Toggle–3
The Fault Relay parameter displays the status of the fault relay.

Busy Relay

Parameter Options: On, Off
Access Level: Read–3; Toggle–3
The Busy Relay parameter displays the status of the busy relay.
0855855eng 6/08
