2.9.5
2.9.6
2.9.7
0855855eng 6/08

Product ID Sensor

Parameter Options: On, Off
Access Level: Read–3
The Product ID Sensor parameter indicates whether a carton is
currently seen by the carton sensor connected to the Product
Sensor I.D. port of the OCU unit and triggers the Product ID (TU
Lookup) bar code scanner to read.

Product ID Scan Enable

Parameter Options: On, Off
Access Level: Read–3; Write–3
When the Product ID Scan Enable parameter is set to On (enabled),
the Product ID scanner will be triggered to read.
The user must set it to Off and back On again to get the Product ID
scanner to retrigger and read a second time. The bar code data that
is read will be displayed inside the Product ID Data field also on the
Machine Diagnostics / OCU menu.

Product ID Data

Parameter Options: On, Off
Access Level: Read–3
The Product ID Data parameter displays inside square brackets the
actual formatted bar code data read by Product ID (TU Lookup) bar
code scanner. The format displayed, which may include bar code
type, number of characters, and the characters read, is configured
by the scanner utility software and programmed into the scanner
before operation.
SECTION 4 Diagnostic Tools
4–27
