The User Interface Module

0855855eng 6/08
The display (1), keypad (2), and LED Indicators (3) are used to
operate, program, and monitor the coder. Various menus will appear
on the display. The Top Level menu is shown below.
1
Job: Chocolate
Status
Counts:
SECTION 2 Basic Operation
Machine: Ready
State: Printing
Ink: OK
Batch : 999
Total : 53796
- Press ENTER to preview image -
Job Reg. Shutdown
+ / -
Select
25 Mar 2008 15:17:49
PH1: On
PH2: On
Main
Menu
2
3
