2.5.16
2.6

Print Station

2.6.1
2.6.2
2.6.3
0855855eng 6/08

Filter Usage Count

Access Level: Read–3
The Filter Usage Count parameter indicates the number of ink pump
strokes between the upper and lower ILS, which on a new filter will
take approximately 400 strokes. When the number is too large, the
system will generate a printhead supply warning and will
recommend replacing the filter.
The number of strokes increases as the filter becomes clogged.
As the filter loads up this number would increase until a warning is
given.
The Print Station menu is used to monitor functioning and diagnose
problems with the print station.

Ink Door Switch

Parameter Options: Door Open, Door Closed
Access Level: Read–3
The Ink Door Switch parameter indicates whether the ink load door
is open or closed.

Ink Door Solenoid

Parameter Options: Locked, Unlocked
Access Level: Read–3; Toggle–3
The Ink Door Solenoid parameter displays the status of the door
solenoid, which locks and unlocks the ink load door.

Line Voltage

Access Level: Read–3
The Line Voltage parameter indicates the percentage of power for
the configured line voltage.
SECTION 4 Diagnostic Tools
4–19
