Replacement; Final Steps - Dover markem-imaje 5200 Service Manual

7.4

Replacement

7.5

Final Steps

0855855eng 6/08
SECTION 6 Field Replaceable Parts
1. Install the new motor to the motor bracket. Install with the
washers and screws previously removed and tighten securely.
2. Place the piston back into the ink pump hole.
3. Install the eccentric on the motor shaft and ensure that the piston
is properly seated on the eccentric.
4. Ensure that the switch lever is not damaged and is properly
located to the eccentric.
5. Tighten the setscrew when the eccentric is flush to the end of the
motor shaft. Ensure that the setscrew engages the dimple on the
shaft.
6. Install new wire ties to the wire harness.
When paragraphs 6.2 through 6.4 are complete:
1. Install the front cover.
NOTE: The ground wire may need to be connected to the print
station first.
2. Connect the power cable and power on the Model 5200/5400.
6–17
