SECTION 6 Field Replaceable Parts
13.4

Replacement

13.5

Final Steps

6–32
1. Reverse the steps in Removal, paragraph 12.3.
2. After the plugs are connected, make sure the wires running up
from the transformer (if in the bottom position) route up behind
the fan (5, Figure 6-25).
3. If the control board was removed, reinstall it.
NOTE: Make sure none of the wires will interfere with the operation
of the fan blades.
NOTE: Push the wires back and down into the wall cutout (6, Figure
6-25).
When paragraphs 12.2 through 12.4 are complete:
1. Install the front cover.
NOTE: The ground wire may need to be connected to the print
station first.
2. Connect the power cable and power on the Model 5200/5400.
0855855eng 6/08
