Install the Rackmount Hardware
No.
4
2.
Position a mounting bracket against the chassis so that the slide rail lock is
at the server front, and the five keyhole openings on the mounting bracket are
aligned with the five locating pins on the side of the chassis.
No.
1
2
3
4
3.
With the heads of the five chassis locating pins protruding through the five
keyhole openings in the mounting bracket, pull the mounting bracket toward
30
SPARC T8-1 Server Installation Guide • June 2019
Description
Installation card
Description
Server front
Slide rail lock
Mounting bracket
Mounting bracket clip
