Remove the tape that secures the slide rail latching bracket to connector D and ensure that the
latching bracket is properly aligned with connector D (panels 1 and 2).
Note - The CMA is shipped with the slide rail latching bracket taped to connector D. You must
remove the tape before you install this connector.
8. Install the CMA's connector D into the left slide rail.
a. While holding the slide rail latching bracket in place, insert connector D and
its associated slide rail latching bracket into the left slide rail until connector
D locks into place with an audible click (panels 1 and 2).
When inserting connector D into the slide rail, the preferred and easier method is to
Note -
install connector D and the latching bracket as one assembly into the slide rail.
b. Gently tug on the left side of the CMA's slide bar to verify that connector D is
properly seated.
Attach the CMA to the Server
