Rear Panel Components
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
Related Information
"Front Panel Components" on page 12
■
"Connect Cables" on page 51
■
"Attach the CMA to the Server" on page 41
■
"Secure Cables to the CMA" on page 60
■
14
SPARC T8-1 Server Installation Guide • June 2019
Description
Power supply 0 (PS 0)
Power supply 1 (PS 1)
PCIe slot 1
PCIe slot 2
PCIe slot 3
DB-15 video connector
SER MGT RJ-45 network port
PCIe slot 4
PCIe slot 5
PCIe slot 6
Network 10GbE 100 Mbps/1 Gbps/10 Gbps ports: NET 0 to NET 3
USB 3.0 connectors (2)
NET MGT RJ-45 network port
