Modem Settings: PPP Mode
SLB™ Branch Office Manager User Guide
Negotiate IP
If the SLB branch office manager and/or the serial device
Address
have dynamic IP addresses (e.g., IP addresses assigned
by a DHCP server), select Yes. Yes is the default.
If the SLB branch office manager or the modem have fixed
IP addresses, select No, and enter the local IP (IP address
of the port) and remote IP (IP address of the modem).
Authentication Enables PAP or CHAP authentication for modem logins.
PAP is the default. With PAP, users are authenticated by
means of the Local Users and any of the remote
authentication methods that are enabled. With CHAP, the
CHAP Handshake fields authenticate the user.
CHAP Handshake
The host/username (for UNIX systems) or secret/user
password (for Windows systems) used for CHAP
authentication. May have up to 128 characters.
Same
Select this option to let incoming connections (dial-in) use
authentication for the same authentication settings as outgoing connections
Dial-in & Dial-on-
(dial-on-demand). If this option is not selected, then the
Demand (DOD)
dial-on-demand connections take their authentication
settings from the DOD parameter settings. If DOD
Authentication is PAP, then the DOD CHAP Handshake
field is not used.
DOD Enables PAP or CHAP authentication for dial-in & dial-on-
Authentication demand. PAP is the default. With PAP, users are
authenticated by means of the Local Users and any of the
remote authentication methods that are enabled. With
CHAP, the DOD CHAP Handshake fields authenticate the
user.
DOD CHAP For DOD Authentication, enter the host/username for
Handshake UNIX systems) or secret/user password (for Windows
systems) used for CHAP authentication. May have up to
128 characters.
Enable NAT Select to enable Network Address Translation (NAT) for
dial-in and dial-out PPP connections on a per modem
(device port or PC Card) basis. Users dialing into the SLB
branch office manager access the network connected to
Eth1 and/or Eth2.
Note:
Network - Settings page for NAT to work. See
Parameters.
Dial-out Phone number for dialing out to a remote system or serial
Number device. May have up to 20 characters. Any format is
acceptable.
Dial-out User ID for dialing out to a remote system. May have up to
Login 32 characters.
Dial-out Password
Password for dialing out to a remote system. May have up
and Retype
to 64 characters.
IP forwarding must be enabled on the
8: Device Ports
6: Basic
