Modem Settings: Text Mode
SLB™ Branch Office Manager User Guide
Initialization Script
Commands sent to configure the modem may have up to
100 characters. Consult your modem's documentation for
recommended initialization options. If you do not specify
an initialization script, the SLB device uses a default
initialization string of AT S7=45 SO=0 L1 V1 X4 &D2
&c1 E1 Q0.
Note:
always be preceded with AT and include E1 V1 x4 Q0 so
that the SLB branch office manager may properly control
the modem.
Modem Timeout Timeout for all modem connections. Select Yes (default)
for the SLB device to terminate the connection if no traffic
is received during the configured idle time. Enter a value of
from 1 to 9999 seconds. The default is 30 seconds.
Caller ID Logging Select to enable the SLB branch office manager to log
caller IDs on incoming calls. Disabled by default.
Note:
user guide.
Modem Command Modem AT command used to initiate caller ID logging by
the modem.
Note:
guide.
Timeout If you selected Text mode, you can enable logins to time
Logins out after the connection is inactive for a specified number
of minutes. The default is No. This setting is only
applicable for text mode connections. PPP mode
connections stay connected until either side drops the
connection. Disabled by default.
Dial Back Users with dial-back access can dial into the SLB branch
Number office manager and enter their login and password. Once
the SLB device authenticates them, the modem hangs up
and dials them back.
Select the phone number the modem dials back on a fixed
number or a number associated with their login. If you
select Fixed Number, enter the number (in the format
2123456789).
Dial-in Host List From the drop-down list, select the desired host list. The
host list is a prioritized list of SSH, Telnet, and TCP hosts
that are available for establishing outgoing modem
connections or for connect direct at the CLI. The hosts in
the list are cycled through until the SLB branch office
manager successfully connects to one.
To establish and configure host lists, click the Host Lists
link.
We recommend that the modem initialization script
For the Caller ID AT command, refer to the modem
For the AT command, refer to the modem user
8: Device Ports
