Current port numbering schemes for Telnet, SSH, and TCP ports display on the left.
The list of ports 1-8 on the right includes the individual ports and their current mode.
Note:
ports.
Icons that represent some of the possible modes include:
Idle
To set up Telnet, SSH, and TCP port numbering:
1. Enter the following:
Telnet/SSH/TCP in Port Numbers
SLB™ Branch Office Manager User Guide
For units with more ports, click the buttons above the table to view additional
The port is not in use.
The port is in data/text mode.
Note: You may set up ports to allow Telnet access using the IP
Settings on the Device Ports – Settings page.
An external modem is connected to the port. The user may dial into
or out of the port.
Telnet in or SSH in is enabled for the device port. The device port is
either waiting for a Telnet or SSH login or has received a Telnet or
SSH login (a user has logged in).
Starting Telnet
Each port is assigned a number for connecting via Telnet.
Port
Enter a number (1025-65535) that represents the first port.
The default is 2000 plus the port number. For example, if
you enter 2001, subsequent ports are automatically
assigned numbers 2002, 2003, and so on.
8: Device Ports
