Telnet/SSH to a Remote Device

The following figure shows a Sun server connected to port 2 of the SLB device.

Figure 13-2. Remote User Connected to a SUN Server via the SLB Device

Remote User
In this example, the sysadmin would:
1. Display the current settings for device port 2:
[SLB]> show deviceport port 2
___Current Device Port
Settings________________________________________________
Number: 2
Modem Settings-------------------Data Settings----------IP Settings---------
Modem State: disabled
Modem Mode: text
Timeout Logins: disabled
Local IP: negotiate
Remote IP: negotiate
Authentication: PAP
CHAP Host: <none>
CHAP Secret: <none>
NAT: disabled
Dial-out Login: <none>
Dial-out Password: <none>
Dial-out Number: <none>
Dial-back Number: usernumber
Initialization Script: <none>
Logging Settings--------------------------------------------------------------
-
Local Logging: disabled
Email Logging: disabled
Byte Threshold: 100
Email Delay: 60
Restart Delay: 60
Email To: <none>
Email Subject: Port %d Logging
Email String: <none>
NFS File Logging: disabled
Directory to log to: <none>
Max number of files: 10
Max size of files: 2048
2. Change the baud to 57600 and disable flow control:
[SLB]> set deviceport port 2 baud 57600 flowcontrol none
Device Port settings successfully updated.
SLB™ Branch Office Manager User Guide
Internet
Name: Port-2
seconds
seconds
Sun Server
Serial Cable to Device Port 2
SLB Branch Office Manager
Baud Rate: 9600
Data Bits: 8
Stop Bits: 1
Parity: none
Flow Control: xon/xoff IP: <none>
Logins: disabled
Break Sequence: \x1bB
Check DSR: disabled
Close DSR: disabled
PC Card Logging: disabled
Log to: upper slot
Max number of files: 10
Max size of files: 2048
13: Application Examples
Telnet: disabled
Telnet Port: 2002
SSH: disabled
SSH Port: 3002
