RJ45 Receptacle to DB9F DCE Adapter for the SLB Device (PN 200.2070A)
Pin 1
RTS 1
DTR 2
Tx 3
Gnd 4
Gnd 5
Rx 6
DSR 7
CTS 8
Use PN 200.2070A adapter with a PC's serial port.
