To add an IP filter:
1. On the IP Filter page, click the Add Ruleset button. The following page displays:
2. Enter the following
Rule Parameters
SLB™ Branch Office Manager User Guide
Ruleset Name Name that identifies a filter; may be composed of letters,
numbers, and hyphens only. (The name cannot start with a
hyphen.)
Example: FILTER-2
IP Address Specify a single IP address to act as a filter.
Example: 172.19.220.64 – this specific IP address only
Subnet Mask Specify a subnet mask to act as a filter.
Example: 255.255.0.0
Protocol From the drop-down list, select the type of protocol through
which the filter will operate. The default setting is All.
