Boot Banks
FTP/TFTP/SFTP
Configuration Management
SLB™ Branch Office Manager User Guide
Bank 1
Version of SLB firmware in bank 1.
Note:
branch office manager booted from.
Bank 2
Version of SLB firmware in bank 2.
Next Boot Bank
Current setting for bank to boot from at next reboot.
Switch to Bank If desired, select the alternate bank to boot from at next reboot.
Copy configuration If checked, will copy the configuration from the current bank to
from Bank 1 to the bank being updated. The two numbers are automatically
Bank 2 during generated so that the first number is the current bank.
firmware update
Copy contents of
If checked, enables you to copy the current boot bank to the
Bank 1 to Bank 2
alternate boot bank. This process takes a few minutes to
complete.
Server
The IP address or host name of the server used for obtaining
updates and saving or restoring configurations. May have up to
64 alphanumeric characters; may include hyphens and
underscores.
Path The default path on the server for obtaining firmware update
files and getting and putting configuration save files.
Login The userid for accessing the FTP server. May be blank.
Password /Retype
The FTP user password.
Password
Configuration
From the option list, select one of the following:
Management
No Save/Restore: Does not save or restore a configuration.
Save Configuration: Saves all settings to file, which can be
backed up to a location that is not on the SLB branch office
manager.
Restore Factory Defaults: Restores factory defaults. If you
select this option, the SLB device reboots after you apply the
update. Select the Save SSH Keys checkbox to save any
imported or exported SSH keys. Select the Save SSL
Certificate checkbox to save any imported certificate. Disabled
by default.
Restore Saved Configuration: Returns the SLB settings to a
previously saved configuration. If you select this option, the SLB
branch office manager reboots after you apply the update.
Configuration Name
If you selected to save or restore a configuration, enter a name
to Save to or
for the configuration file (up to 12 characters).
Restore From
12: Maintenance and Operation
The word "current" displays next to the bank the SLB
