IP Settings

SLB™ Branch Office Manager User Guide
DOD Enables PAP or CHAP authentication for dial-in & dial-on-
Authentication demand. PAP is the default. With PAP, users are
authenticated by means of the Local Users and any of the
remote authentication methods that are enabled. With
CHAP, the DOD CHAP Handshake fields authenticate the
user.
DOD CHAP For DOD Authentication, enter the host/username for
Handshake
UNIX systems) or secret/user password (for Windows
systems) used for CHAP authentication. May have up to
128 characters.
Enable NAT
Select to enable Network Address Translation (NAT) for
dial-in and dial-out PPP connections on a per modem
(Device Port or PC Card) basis. Users dialing into the SLB
branch office manager access the network connected to
Eth1 and/or Eth2.
Note:
Settings page for NAT to work. To enable, click the IP
Forwarding link to display the Network Settings page. See
Dial-out Phone number for dialing out to a remote system or serial
Number device. May have up to 20 characters. Any format is
acceptable.
Dial-out User ID for dialing out to a remote system. May have up to
Login 32 characters.
Dial-out Password Password for dialing out to a remote system. May have up
and Retype to 64 characters.
Restart Delay The number of seconds after the timeout and before the
SLB branch office manager attempts another connection.
The default is 30 seconds.
Service The available connection services for this modem port
(Telnet, SSH, or TCP). Only one can be active at a time.
The default is None.
Telnet Port Telnet session port number to use if you selected Telnet.
Defaults:
Upper PC Card Slot: 2049
Lower PC Card Slot: 2050
Range: 1025-65535
SSH Port The SSH session port number to use if you selected SSH.
Defaults:
Upper PC Card Slot: 3049
Lower PC Card Slot: 3050
Range: 1025-65535
IP forwarding must be enabled on the Network -
9: PC Cards
121
