9.7.4

Device Information Packet

Packet ID
Length
Field # Bytes
Offset
1 0
2 4
3 8
4 12
5 16
6 20
Table 20: Device information packet
9.7.5

Restore Factory Settings Packet

Packet ID
Length
Field # Bytes
Offset
1 0
Table 21: Restore factory settings packet
9.7.6

Reset Packet

Packet ID
Length
Field # Bytes
Offset
1 0
Table 22: Reset packet
9.8

State Packets

Spatial supports a large number of packets providing extensive functionality. However for the
majority of users the easiest approach is to configure Spatial using the Spatial Manager software
and then support only the single system state packet shown below in section 9.8.1. Advanced
functionality can be added through the other packets.
Device Information Packet
Data Size
Type
u32 4
u32 4
u32 4
u32 4
u32 4
u32 4
Restore Factory Settings Packet
Data Size
Type
u32 4
Data Size
Type
u32 4
Spatial OEM Reference Manual
Description
Software version
Hardware revision
Serial number part 1
Serial number part 2
Serial number part 3
Description
Verification Sequence (set to 0x85429E1C)
Reset Packet
Description
Verification Sequence (set to 0x21057A7E)
Page 54 of 88
Version 2.7
3
24
Device ID
4
4
5
4
