4.8 Power Consumption
250
200
150
100
50
0
2
Illustration 14: Maximum and typical current consumption across operating voltage
4.9

Sensor Calibration

Spatial's sensors are calibrated for bias, sensitivity, misalignment, cross-axis sensitivity, non-
linearity and gyroscope linear acceleration sensitivity across the full operating temperature range
and for each of the three sensor ranges.
4 6 8
Voltage (V)
Spatial OEM Reference Manual
10 12 14
Page 23 of 88
Version 2.7
Maximum
Typical
16 18
