Interoperability With Different Voltage Systems; Reset Line; Basic Connection - Advanced Navigation Spatial OEM Reference Manual

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Table 7: Pin allocation table
5.3.1

Interoperability with Different Voltage Systems

All signals are 3 volt level, however inputs are tolerant to 5 volt signals from the target interface. If
you require a different voltage level to be compatible with your target system it is recommended
that you install a voltage level translator between the signals of each device. To power the
translator 3V is provided on pin 7 of the Spatial OEM connector. This supply is only capable of
driving up to 50mA and should be appropriately decoupled when powering a circuit.
5.3.2

Reset Line

The reset line is internally pulled high on Spatial OEM. This pin must be left floating for normal
operation. If a user wishes to reset Spatial OEM the pin can be pulled low externally to force a
reset. It is important that this signal is not driven high under any circumstances as it will prevent the
Spatial OEM from functioning correctly. Please keep the reset line track length to a minimum to
avoid noise.
5.3.3

Basic Connection

Please see Illustration 20 for the basic electrical connections required by Spatial OEM.
