Hardware Specifications

Parameter
Operating Voltage
Input Protection

Power Consumption

Backup Battery Capacity
Backup Battery Charge Time
Backup Battery Endurance
Operating Temperature
Shock Limit
Dimensions
Weight
Table 5: Hardware specifications
4.7

Electrical Specifications

Parameter
Input Supply Voltage
Input Protection Range
Output Voltage Low
Output Voltage High
Input Threshold Low
Input Threshold High
Input Voltage
Output Current
Active Antenna Supply Voltage
Antenna Supply Current
Table 6: Electrical specifications
Spatial OEM Reference Manual
Minimum
Power Supply
4.2 V
-40 V
GPIO
0 V
2.4 V
2 V
0 V
GNSS Antenna
2.5 V
Page 22 of 88
Version 2.7
Value
4.2 to 36 V
± 40 V
95 mA @ 5 V (typical)
> 24 hrs
30 mins
> 10 years
-40 °C to 85 °C
2000 g
25 x 25 x 6 mm
4 grams
Typical
2.65 V
Maximum
36 V
40 V
0.4 V
3 V
0.8 V
5.5 V
10 mA
2.8 V
57 mA
