74 General Maintenance
11. Turn OFF the engine.
12.
Proceed with the tagout/lockout procedure. Refer to "Locking Out and Tagging Out the
Vehicle" on page 26.
Danger! Never get on the hopper area while the engine is running.
13. Use an Allen key to loosen the locknut on the limit switch and determine the contact point where
the triggering should occur by moving the rod.
14.
Once you have determined the contact point where the triggering should occur, retighten the
locknut.
15.
Start the engine and engage the hydraulic system (P
Caution
Make sure the ball valve on the suction line is fully open before starting the vehicle.
16.
Fully retract the packer and press the green P
efficiency of the limit switch.
N : Repeat this procedure until you achieve the proper settings for the limit switch.
OTE
B. To adjust the packer extend proximity switch:
1.
Set the parking brake.
2.
Start the engine and engage the hydraulic system (P
Usually, the packer extend proximity switch needs adjustment when the last follower panel
moves past the switch without triggering any signal. In such a case, the packer continues its
forward motion inside the body as in Eject mode.
3.
Press and hold the Auto-Eject switch on the multiplexed control panel (see Figure 3-39). Keep
this switch down until the tailgate is fully open and the last follower panel clears the proximity
switch in the hopper.
As soon as you release the Auto-Eject switch, the packer will stop moving.
Caution!
Make sure no one is standing behind the truck when you operate the tailgate.
4. Turn OFF the engine.
switch activated).
UMP
button to start a complete cycle and test the
ACK
switch activated).
UMP
