Cushioning cartridges on up/down cylinder (see Figure 10-20) should be torqued to 28 ft-lb.
I :
MPORTANT
: Picture provided above is for illustration purposes only. It may differ from actual part.
N
OTE

Adjusting Arm Vane Pump Relief Valve

Usually, there is no arm vane pump relief valve on an A
A
UTOMIZER
pump.
Tighten the relief valve completely on the pump.
The arm (retract/extend) and gripper (up/down movement) operating pressure is the same as the
arm valve main relief
adjustments are required for these functions. Only "gripper close" requires proper adjustment to
prevent crushing roller carts. See Adjusting Arm Speed on page 241 to adjust the gripper load sense
relief valve.
See Pressure and Cycle Time Chart - PVG-32 Circuit on page 150 for a complete list of pressure settings
and cycle times for each proportional valve function.
For more information, see Adjusting Pressure on the Proportional Valve on page 143.
To adjust pressure on a 96-gallon gripper, see Adjusting Pressure on 96-Gallon Gripper on page 144.
To adjust pressure on a 300-gallon gripper, see Adjusting High Pressure on 300-Gallon Gripper on
page 145 and Adjusting Low Pressure on 300-Gallon Gripper on page 147.
Table 1 Arm operating pressure and cycle times
Arm function
Extension/retraction
Gripper up
Gripper down
Gripper close
Gripper open
1. If the arm is equipped with a 300-gallon/1100-L gripper, the arm valve main relief must be set to 2700 psi.
™ F E vehicle is equipped with such a valve, it would be located on the top of the
ULL JECT
1
. Table 1 lists the operating pressure and cycle times for each arm function. No
Pressure setting (psi)
2000 (96 gallons, std & HD)
2700 (300 gallons/1100 L)
2000 (96 gallons, standard)
2000 (96 gallons, HD)
2700 (300 gallons/1100 L)
2000 (96 gallons, std & HD)
2700 (300 gallons, HD)
1200 (96 gallons, std & HD)
1200/1800 (300 gallons, HD)
1200 (96 gallons, std & HD)
1200 (300 gallons, HD)
™ F E . However, if your
UTOMIZER ULL JECT
Cycle time (sec.)
3.25/3 (all models)
3 (96 gallons, std & HD)
3.6 (300 gallons, std & HD)
2.5 (all models)
1.5 (96 gallons, std & HD)
2.25 (300 gallons, HD)
1.5 (96 gallons, std & HD)
2.5 (300 gallons, HD)
