62 General Maintenance
You may also secure the cylinder with slings attached to the lifting rings above the cylinder
(see Figure 3-42).
Warning!
Use caution when lowering /moving the cylinder inside the body to avoid accidents and
injuries.
4. After having correctly positioned the cylinder rear-end into the front beam and aligned its
bushing with the bracket holes, insert the pin (see Figure 3-44) through the holes to hold the
cylinder in place.
5. Connect the greasing hose to the cylinder port.
6. Connect both hydraulic hoses to the cylinder.
7.
Put back both pin plates and secure them to the bracket with the same bolts (see Figure 3-43).
8.
Reinstall the access cover (see Figure 3-44).
9.
Through one of the sump boxes (see Figure 3-42), remove the piece of wood and/or slings that
were used to support the weight of the cylinder.
10. Under the follower panels, place a piece of wood that will support the cylinder front-end during
the extension step of the cylinder.
11.
Start the engine and engage the hydraulic system (P
Wait for the air pressure to reach 70 psi before engaging the hydraulic system.
Caution
Make sure the ball valve on the suction line is fully open before starting the vehicle.
12. On the packer control station, press the green P
packer cylinder.
Be careful when the cylinder reaches the packer; its front-end must go inside the packer through
the tunnel hole (see Figure 3-37) up to the tip of the packer tunnel.
Warning!
Slowly extend the cylinder to avoid impact that could cause damage to the equipment.
13.
When the cylinder eye-end is aligned with the side holes of the tunnel tip, press the red
E
MERGENCY
14. Proceed with the tagout/lockout procedure. Refer to "Locking Out and Tagging Out the
Vehicle" on page 26.
15.
Secure the cylinder front-end with the pin (see Figure 3-27).
16.
Put the bolt back in to secure the pin cover to the tunnel tip.
S button (see Figure 3-25).
TOP
switch set to "ON").
UMP
button (see Figure 3-23) to fully extend the
ACK
