Pressure and Cycle Time Charts

Table 2 Pressure and Cycle Time Chart - VG-35 Circuit
Main relief valve (4x2 chassis w/ tag or 6x4
chassis)
Dump valve R5P (if adjustable) - 4x2
chassis w/ tag or 6x4 chassis
Packer extend
Packer retract
Complete packer cycle
Complete packer cycle
Pilot generating relief valve on utility
section (electro-hydraulic valve only)
Pressure reducing valve on utility section
(electro-hydraulic valve only)
Tailgate up
Tailgate down
Tailgate holding valve (to keep TG closed)
Function
Pressure Engine
Setting rpm
2500 ± 50 psi 700
2750 ± 50 psi 700
2000 ± 50 psi 700
system pressure 700
system pressure 700
system pressure 1500
420 ± 20 psi 700
550 ± 20 psi max.
system pressure w/ 700
power bleed
system pressure w/ 700
velocity fuse to
drain
600 ± 50 psi 700
Hydraulic System 149
Minimum Maximum
Cycle Time Cycle Time
(sec.) (sec.)
n/a n/a
n/a n/a
19 23
13.5 16.5
n/a n/a
n/a n/a
15.0 21.0
15.0 26.0
n/a n/a
