218 Multiplexing
Figure 9-18 Buzzer

Plugging a Computer

The in-cab control panel of the A
connect a laptop computer for reprogramming purposes (see Figure 9-19). Connecting a laptop to
this plug requires special hardware and software (included in the service kit). For more information
on this, contact the LabriePlus Service Department. In advanced troubleshooting process, a modem
may be connected to this plug to help Labrie's technicians to detect and pinpoint the cause of body-
related problems.
Figure 9-19 Computer plug
N : Location of the computer plug on the control panel may be different from what is shown in the
OTE
above picture.

Replacing the CAN Bus-Based Multiplex Joystick

Should the CAN bus-based multiplex joystick need to be replaced for any reason, it will have to be
replaced with a new joystick of the same kind and same part number in order to insure continued
proper operation of the multiplex system. Do not use other kind of joysticks even if they bear
similarities to the CAN bus-based joystick. For more information on CAN bus-based joystick
replacement, contact LabriePlus.
™ F E has a computer plug that can be used to
UTOMIZER ULL JECT
