Multiplexing

As Labrie Enviroquip Group vehicles become more
and more efficient, they require more automation
features and thus some programming. Currently,
A ™ F
UTOMIZER
programming of Labrie's CAN bus-based multiplexed
system. The following pages provide the necessary
information for this task.

Labrie's Multiplexed System

Labrie has equipped your A
unit with a CAN bus-based multiplexed system, which
integrates a monitor, a control panel, a joystick, and a
set of electronic controllers. This whole system has
been designed to help you operate your unit in an
efficient and easy way. Labrie's multiplexed system is
reliable and safe and it requires less wiring harnesses to
operate. It can also monitor various function status of
the body and display warning and caution messages.
Through its monitor (see Figure 9-1), Labrie's
multiplexed system informs you of any malfunctions
that may occur during the operation of the truck.
Various caution and warning messages can be
displayed on the monitor, depending on the
seriousness of the situation. Yellow-highlighted
messages indicate that caution should be used while
red-highlighted messages indicate a warning situation
that must be dealt with quickly.
Figure 9-1 Monitor
