178 Troubleshooting
Figure 8-1 Digital Multimeter or VOM (Volt-Ohm-Milliammeter)
N : The ammeter must support at least 10 amps.
OTE
Figure 8-2 Jumper wire with alligator clips
Figure 8-3 0–4000 psi oil pressure gauge (left), ball-end hex wrench (metric and
N : Some troubleshooting tasks require the use of two (2) 0-4000 psi pressure gauges.
OTE
0–4000 psi
pressure gauge
(Part# HYF00910)
Female
quick coupler
(Part# HYF10195)
) [right]
SAE
