182 Troubleshooting
Problem
Packer moves forward but
stops at the end of stroke
Packer does not perform
enough cycles
Backup alarm and warning
buzzer inside the cab sound
all the time
Arm is too fast/too slow
Flashing lights on
dashboard always blinking
Arm does not respond to
joystick (assuming that
PTO/P
UMP
engaged)
Possible causes
RHS hopper door open
Packer sliding shoes are worn
out
Packer extend limit/proximity
switch is misaligned
Multi-cycle module
programming
Misaligned tailgate proximity
switch
Faulty proximity switch
Faulty harness
Flow limiter adjustment on arm
control valve
Misaligned arm stowed limit
switch
Cut off or defective power
cables
Faulty limit switch
Cut off or defective power
cables
switch is
Faulty joystick
Solution
Close RHS hopper door.
Replace sliding shoes. See Replacing
Sliding Shoes on page 51.
Adjust switch. See Adjusting Packer
Extend Limit/Proximity Switch on
page 73
Reprogram the module for higher
number of cycles (see Warning
Buzzer on page 217).
Adjust tailgate proximity switch (see
Adjusting Tailgate Unlocked
Proximity Switch on page 78).
Check the proximity switch with a
multimeter or for proper
VOM
operation (O /O or click).
N FF
Replace if necessary.
Check for continuity on the
electrical harness that is connected
to the proximity switch. Change the
electrical harness if necessary.
Recalibrate cylinder speed (see
Adjusting Arm Speed on page 241).
Align switch lever with gripper
finger (see Adjusting Arm Stowed
Limit Switches on page 82).
Perform a continuity test on the
cable. Replace faulty cables if
necessary.
Replace faulty limit switch.
Follow wires on the electrical
schematic for 12-volt supply (move
joystick to get signal).
Contact LabriePlus.
